Warehouse Farm Monitoring systems Point to point Extend network signal 5ghz 3km 24V PoE 2 LAN 14dBi Wireless Bridge Wifi CPE

How to Access and Setting the Wireless Bridge CPE Through Computer Access:
Step 1. Use a PoE adapter to power the wireless bridge through a network cable. Pay attention to the "PoE" and "LAN" ports marked on the PoE adapter, and power is supplied by POE instead of a DC power interface.

Step 2. Use a network cable to connect the CPE "LAN" port, connect the network cable other ends to the PoE Adapter "POE" port, use another network cable to connect to the "LAN" port of the PoE adapter, and connect the other end of the network cable to the computer's "LAN" port.

Step 3. Find the number of the Wireless Bridge CPE digital display tube. For example, the number is 1 and the CEP is the A master bridge, then the IP of this CPE is 192.168.255.101; if the CPE is the B slave bridge, then the IP address of the CPE is 192.168.255.201.(There is a table corresponding to a number and IP in the manual)

Step 4. Very important step: Modify your computer's IP address, change your computer's IP address to 192.168.255.xxx(192.168.255.xxx cannot be the same as the IP of the CPE), make your computer's IP and the bridge's IP address be on the same network segment so that you can access them. Please refer to the manual to modify the computer IP address step or Google searches how to modify the computer IP address, it is very simple.

Step 5. After you modify your computer's IP address, you open the computer browser and enter the IP address of the wireless bridge to access. For example, enter 192.168.255.101 to access.

Step 6. Enter the account password "admin/admin" to access, and set it after successful access.

How to find and change CPE450 WiFi SSID and password?

1. Find the WiFi hotspot password of CPE450, path: Setting-->Wireless--> Name(SSID) and Password.

2. Enter the new SSID and password and save.

What is a wireless bridge?

WiFi bridge is widely used in warehouses, farms, and house lane monitoring systems. Point to point extend network WiFi range, extend the network in the house to your barn, garage, church, warehouse, and even neighbor's house through wireless bridge signal transmission.
It is equivalent to a network cable, transmitting network signals via wireless way.It uses wireless communication technology to transmit network data using air as a medium to carry out long-distance point-to-point or point-to-multipoint interconnection. Wireless Signals Are Everywhere In Life

What can a wireless bridge do?
Extend the network to another building, and it can also extend your monitoring range.

*3Km 5.8G wireless transmission equipment. It uses wireless communication technology to transmit network data using air as a medium to carry out long-distance PtP or PtMP interconnection. The working data link layer realizes the interconnection and transmission of local area networks.

* Wireless bridge IP65 dustproof and waterproof, lightning protection,and antifreeze, High/low temperature resistance, is very suitable for outdoor use.

*The FCC ID: 2A6EJ-CPE450, This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Accurate Operating Frequencies: The frequency range that complies with FCC Rule Parts 15E is 5180.1-5240.0 MHZ and 5745.0-5825.0 MHZ

* digital display bridge, transmission/receiver automatic networking, support point-to-point, point-to-multipoint, transmission/receiver flexible switching. WDS networking mode, video network dual compatible.Deep protocol optimization for wireless video surveillance transmission to ensure high-speed video transmission and smooth video surveillance, and the underlying wireless driver is optimized in-depth, with stronger anti-interference ability and better stability

Tuoshi is one of the biggest manufacture in China which focus on wifi and 4G products for more than 16 years.

We have our own SMT line Assemble line and Moulding machines. Quality is our life, we always regard quality

as the top important thing, so we have full system about quality:
1: Complete team about IQC, IPQC, FQC, OQC, and testing lab center.
2: Certified by ISO9001, ISO14001, ROHS.
3: Every work know how to check the product at his own stage and also can check the last step quality.

Test Equipment and Facilities:
1: R&S CMW500 is the most popular tester in the world for 4G devices RF testing.
2: Agilent 8960 is the most popular tester in the world for wifi testing.
3: Tuoshi does 100% test for all products.

Our prodcut range from 4G Ufi/mifi/router/CPE,wifi antenna/wifi repeater/wifi bridge/wifi router.

We have very wide cooperation with distributors for wifi products from USA SPAIN Morroco brazil

and Indonesia market.

If you are looking for a reliable supplier, please feel free to contact us.
